Informazioni di Base.
Descrizione del Prodotto
Disegni dei prodotti
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00PoYikBUEqCzu/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
Parametri del prodotto
POLLICI | Mm | Mm | Modello | MAX | MIN. BP | TP. | Sicuro | Modifica lunghezza | Rmin. MIN | Peso | ||||
MPa | Bar | Psi | MPa | Bar | Psi | Bar | Fattore | WP. | Mm | Gr/m | ||||
1/8 | 4,0 | 8,6 | RSD101A | 28 | 280 | 4060 | 84 | 840 | 12180 | 420 | 3:1 | ±1,5% | 20 | 53,0 |
3/16 | 5,0 | 10 | RSD101B | 28 | 280 | 4060 | 84 | 840 | 12180 | 420 | 3;1 | ±1,5% | 30 | 68 |
1/4 | 6,3 | 11,2 | RSD101C | 28 | 280 | 4060 | 84 | 840 | 12180 | 420 | 2.5:1 | ±1,5% | 40 | 78 |
1/8 | 4,0 | 9 | RSD102A | 40 | 400 | 5800 | 100 | 1000 | 14500 | 500 | 2.5:1 | ±1,5% | 20 | 62 |
1/8 | 4,2 | 8,8 | RSD102B | 36 | 360 | 5220 | 90 | 900 | 13050 | 2.5:1 | ±1,5% | 20 | 58 |
DIAMETRO ESTERNO TUBO: 8,6+0.15/-0.1MM
ID TUBO: 4,0±0,1MM
Max Betriebsdruck Statistics: 280Bar
Pressione di prova: 420 bar
Pressione di scoppio a 20ºC: 840 Bar
Fattore di sicurezza: 3:1
Peso: 5,5kg/100m
Intervallo di temperatura: -40ºC-+80ºC
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00DkYionUjhBpg/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00iqRVbEUyOBru/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
Utilizzo del prodotto
1. Soluzione flessibile di lubrificazione a energia eolica
2. Soluzioni di tubi flessibili di lubrificazione per uso automobilistico
3. Soluzioni di tubi flessibili di lubrificazione per macchine minerarie
4. Soluzioni di tubi flessibili di lubrificazione per macchine da costruzione
5. Soluzioni di tubi flessibili di lubrificazione con terminale di attacco
I nostri servizi
1. L'installazione rapida può essere eseguita con un nucleo diritto, un nucleo piegato (90°, 45°) o 7/16 raccordi JIC.
2. Il tubo flessibile di ingrassaggio è molto flessibile, rende facile il funzionamento delle tubazioni dove necessario.
3. Possiamo accettare la stampa personalizzata, OEM.
4. Possiamo fornire il grasso.
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00lbYVorfRIvgz/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
Prodotti aziendali
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00lkUWoiGhOvzr/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00WoYikeRKHCgu/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00icRVonfqHvpr/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00boRiqQUnJMpz/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00kbUlqrGtIegz/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00cqRlbVGMYvgu/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00kbfWcvUnbBuz/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00qoflcNYBberz/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
![High Pressure Lubrication Oil Pumps Hose Synthetic Fibers Grease Hose](http://img6.grofrom.com/www.xusahosegroup.it/226f3j00CoYlqafrVBgz/High-Pressure-Lubrication-Oil-Pumps-Hose-Synthetic-Fibers-Grease-Hose.webp)
Profilo aziendale
Qingdao Restart New Material Technology Co., Ltd è una famosa azienda che produce tubi flessibili di lubrificazione e tubi in TPU. Non solo forniamo ai clienti prodotti standard ad alta affidabilità e a costi contenuti, ma sviluppiamo continuamente nuovi prodotti in base alle più recenti esigenze dei clienti per soddisfare le specifiche esigenze applicative dei vari settori.
Il nostro rigoroso processo e la materia prima di alta qualità lo rendono idoneo a superare la certificazione ISO9001, ISO45001e ISO14001. L'azienda mantiene una vasta collaborazione con WANHUA , DuPont, Arkema e altri fornitori internazionali di materiali leader, e ha mantenuto la massima competitività nello sviluppo di nuovi materiali e nelle nuove applicazioni tecnologiche.
